Session 1A: Foundations — Concepts
- Overview: REV DUO, shop policies, PPE
- Tools: drivers, hex keys, measuring
- Principles: strength, stability, balance
Carnegie Mellon Robotics Academy: Mechanical Foundations
$299.99
Join Now
Mastering Mechanical Design and Robotics with Hands-On REV DUO Projects
Sessions per week
Please choose
Group Size
Please choose
Student's Name
Enter your text
Student's Grade
Enter your text
Additional Name (if signing up more than one)
Enter your text
Additional Grade
Enter your text
Buy once or subscribe? Subscribers get 10% off classes, camps, and events after 3 months, valid until July 1, 2026.
1
Save this product for later
Have questions?
Carnegie Mellon Robotics Academy: Mechanical Foundations
Class Meeting Schedule: Mondays/Wednesdays 6:00 - 7:30
Mechanical Foundations with REV DUO — 24-Session Course
Class Size: 1–4 students. Additional instructors may be added as needed to support newcomers and maintain quality.
Total Duration: 3–6 months.
This project-based course emphasizes hands-on learning. Students who watch videos at home, come prepared, and stay on schedule can complete the program in about 3–4 months with a 1.5-hour weekly class commitment. To earn a certificate, students must:
- Complete all projects to specification (reviewed and approved by instructors before upload).
- Pass the final exam with a score of 70% or higher.
Project timelines vary by age, manual dexterity, and attention span.
The certification exam costs an additional $200.
Group Discounts: 10% (2–3 members), 25% (4 members).
Open Enrollment: New students are welcome to join at any time. Self-paced structure makes mid-course additions simple.
24-Session Robotics Course (REV DUO)
Session 1B: Foundations — Build
- Mini-project: Stable rectangular base
- Square, align, torque checks.
- Peer inspection and notes
Session 2A: Reinforcement & CoG — Concepts
- Gussets, triangles, and cross-bracing theory
- Center of gravity and tipping models
- Plan reinforcement for the base
Session 2B: Reinforcement & CoG — Build/Test
- Apply bracing to the base.
- Tipping tests and iteration
- Record before/after results
Session 3A: 3D Structures — Concepts
- From frames to 3D assemblies
- Joint integrity, fastener selection
- Torque specs and thread engagement
Session 3B: 3D Structures — Build/Test
- Mini-challenge: 3D load-bearing build
- Deflection and load tests
- Improve joints for stiffness.
Session 4A: Project — Riverbed Crane (Plan)
- Requirements, sketching, constraints
- Risk assessment and test plan
- Bill of materials and schedule
Session 4B: Riverbed Crane (Build Sprint 1)
- Assemble the frame and base.
- Verify alignment and rigidity.
- Document issues and fixes
Session 5A: Motion Basics — Concepts
- Torque, speed, power trade-offs
- Mechanical advantage, ratio math
- Transmission types overview
Session 5B: Motion Basics — Build
- Mini-project: Motorized fan
- Measure RPM vs load qualitatively
- Safety and balancing
Session 6A: Gears & Sprockets — Concepts
- Simple/compound gear trains
- Chains, sprockets, tensioning theory
- Backlash and alignment
Session 6B: Gears & Sprockets — Build/Test
- Assemble two ratios for comparison.
- Tune for speed vs torque.
- Record performance differences
Session 7A: Optimized Lifting — Concepts
- Staged reductions and efficiency
- Backdriving and holding strategies
- Select ratios for crane lift
Session 7B: Optimized Lifting — Upgrade Build
- Install lift gearing/chain system.
- Guide rails and supports
- Initial lift validation
Session 8A: Drivetrains — Concepts
- Chassis, wheelbase, weight distribution
- Motors, wheels, and gearboxes choices
- Layout and mounting strategy
Session 8B: Drivetrains — Build
- Mini-project: 2-motor drivetrain
- Square frame, bearing alignment
- Smoke test and checklist
Session 9A: Advanced Drives — Concepts
- Omni vs traction vs mecanum
- Turning dynamics, scrub, CoF
- Wheel selection for terrain
Session 9B: Advanced Drives — Challenge
- Tune gearing/tires for ramp.
- Timed climb and descent
- Iterate for target performance.
Session 10A: Project — Obstacle Drive (Plan)
- Select drivetrain architecture
- Bill of materials and layout
- Metrics: climb angle, speed, control
Session 10B: Obstacle Drive (Build)
- Assemble chassis and transmission.
- Tension chains/belts; align gears
- Initial drive tests
Session 11A: Integration — Concepts
- Intro to sensors/encoders
- Power routing, cable management
- Safety interlocks and guards
Session 11B: Integration — Apply
- Add a sensor/encoder to a subsystem.
- Service loops, labeling
- Reliability checks
Session 12A: Capstone — Prep
- Combine lift + mobility goals.
- Test plan, data sheets, rubric
- Assign roles and timeline.
Session 12B: Capstone — Demo & Assessment
- Final challenge run(s)
- Data, presentation, reflection
- Final exam (70%+ to pass)
